Level comes in 3 sizes to suit most adults.
Small 5'1" - 5'7"
Medium 5'7"- 5'11"
Large 5'11" - 6'4"
| Frame Size | Small | Medium | Large |
|---|---|---|---|
| Height | 5'1" - 5'7" | 5'7" - 5'11" | 5'11" - 6'4" |
| Top Tube Length | 562mm | 579mm | 603mm |
| Reach | 361mm | 364mm | 385mm |
| Head Tube Length | 140mm | 150mm | 160mm |
| Standover Height | 590mm | 660mm | 690mm |
| Wheelbase | 1090mm | 1097mm | 1122mm |
| Min Saddle Height | 805mm | 835mm | 907mm |
| Max Saddle Height | 965mm | 1015mm | 1080mm |
| MOTOR 750W (Peak) 500W (Sustained), 48V Brushless Rear Hub Motor | THROTTLE Throttle on demand - Throttle from a complete stop | DISPLAY M5 LCD Smart Easy Read Display with Backlight |
| SPEED Up to 28 MPH on Pedal Assist and 20 MPH on Throttle | BATTERY Removable Internal Lithium-ion 48V, 14Ah (672Wh) | SENSORS Cadence Sensor, Speed Sensor |
| PEDAL ASSIST 5 Levels | CHARGER 48V 3 Amp Fast Charger, 4-5 Hour Charging | RANGE 40 Miles Average |
| FRAME 6061 Double-Butted Aluminum Alloy with Internal Battery | WEIGHT 62lbs | PEDALS 9/16" Alloy Platform |
| FORK Coil spring suspension, thru-axle, 75mm travel, with lockout | WEIGHT LIMIT Maximum Payload Capacity: 300 lbs | KICKSTAND Included, Rear Mount |
| BOTTOM BRACKET Square Taper, Sealed | CRANKSET 170mm w/ 46 T | REAR DERAILLEUR 8 Speed |
| CASSETTE 12-32T, 8 Speed Cassette | SHIFT LEVER 8 Speed | BRAKES Hydraulic Disc Brakes, 180mm Rotors |
| CHAIN 8 Speed | RIM Double Wall Aluminum 36h Front & Rear | SPOKES Black Stainless 13 Gauge |
| TUBES Butyl Rubber, Schrader Valve | HUBS 36H Disc Thru-axle Front, Nutted Rear | TIRES 27.5" Ebike Rated, Reflective Sidewalls |
| SADDLE Aventon by Velo | SEATPOST Forged Alloy, 27.2mm, 2-Bolt Clamp | STEM Threadless, 31.8mm, 7 Degree Rise |
| SEAT CLAMP Quick Release | HANDLEBARS Aluminum 31.8mm, 680mm | HEADSET VP Sealed Bearing Headset |
| GRIPS Ergonomic Comfort |
Level ships as a Class III ebike. If you are riding on private property or in an area without ebike speed restrictions, the speed limit can be modified in the settings. Level will also operate with the throttle unplugged and removed, should you want to ride in an area where throttles are not allowed.
Aventon ebikes are built to the IPX4 water-resistant standard. IPX4 means that your bike is resistant to water splashes from any direction. This means it’s OK to ride or park your ebike in the rain. It won’t be harmed by spray from a wet road or raindrops. Your ebike is not intended to be submerged or subjected to a pressurized spray. Don’t use a pressure washer or sprayer to clean your ebike.
